Siemens Breaker 5SY6206-7CC

The Siemens Breaker 5SY6206-7CC is a Miniature Circuit Breaker (MCB) with 2 poles, a rated current of 6A, and a Type C tripping characteristic.

Specification:

• Product Type: Miniature Circuit Breaker (MCB).
• Number of Poles: 2 poles (2P).
• Rated Current (In): 6 A.
• Operational Voltage: 230/400V AC, 72V DC.
• Mounting Method: DIN rail.
• Dimensions Width: 36 mm, Depth: 70 mm, Height: 90 mm.

Features:

• Touch Protection: The product features touch protection for enhanced safety during installation and operation.
• Conductor Connections: It has top and bottom combination terminals that allow for easy connection of solid or stranded conductors with cross-sections ranging from 0.75 mm² up to 35 mm².
• Modular System: It is part of the Siemens SENTRON modular system, ensuring compatibility with a wide range of accessories such as auxiliary switches and fault signal contacts.
