Siemens Breaker 5SY6332-7CC

The Siemens Breaker 5SY6332-7CC is a 3-pole Miniature Circuit Breaker (MCB) with a rated current of 32 A and a type C tripping characteristic.

Specification:

Product Type: Miniature Circuit Breaker (MCB)
Number of Poles: 3-pole (3P)
Rated Current (In): 32 A
Rated Operating Voltage: 400 V AC and up to 72 V DC
Tripping Characteristic: Type C
- Type C curve is suitable for general applications where moderate inrush currents are expected, such as lighting and most motor loads.
Breaking Capacity: 6 kA (6000 A) in accordance with IEC/EN 60898-1
Standards: Meets IEC/EN 60898-1 and IEC/EN 60947-2 standards
Mechanical Service Life: Typically 10,000 switching cycles
Mounting: Designed for snap-on mounting onto a standard 35mm DIN rail
Protection Class: IP20 (finger-safe/touch-proof) with connected conductors
