Siemens Connectors 6GK1907-0DB10-6AA3

The Siemens Connector 6GK1907-0DB10-6AA3 is an M12 Power PRO plug-in cable connector designed for 24 V DC power supply connections in industrial communication applications. It features 4 poles, A-coding, and is sold in a pack of 3 units.

Specification:

• Connector Type: M12 Power PRO plug-in connector (circular connector for field assembly).
• Recommended Use: Specifically designed for connection to the PS791-1PRO power supply unit for a 24 V DC supply voltage.
• Number of Poles: 4 poles.
• Cable Connection: Utilizes integrated screw contacts for 2-core power cables.
• Connectable Cable Diameter: 6 to 8 mm.
• Connectable Conductor Cross-Section: 0.75 mm².
• Enclosure Material: Plastic.
• Environmental Conditions:
  • Operating temperature: -40 to +70 °C.
  • Resistant to water.
• Dimensions: Approximately 19 mm width, 19 mm height, and 73 mm depth.
• Additional Features: Silicon-free and equipped with strain relief.
• Country of Origin: Germany.
