Siemens Control Panels 6FC5303-0AF22-0AA1

The Siemens control panel with part number 6FC5303-0AF22-0AA1 is a SINUMERIK Machine Control Panel (MCP) 483C PN designed for operating industrial CNC machines.

Specification:

Part Number: 6FC5303-0AF22-0AA1.
Product Type: SINUMERIK Machine Control Panel (MCP) 483C PN.
Manufacturer: Siemens.
Input Voltage: 24 VDC.
Cutout Dimensions (Mounting Surface): 450 mm (width) x 135 mm (height).
IP Rating (Front Side): IP54 (IP65 with mounting frame).
Operating Temperature Range: 0 to 45 °C at the front, 0 to 55 °C at the rear.
Net Weight: Approximately 1.800 kg (1.8 kg).
