Siemens Control Unit 6AU1435-2AA00-0AA0

The Siemens Control Unit 6AU1435-2AA00-0AA0 is a SIMOTION D435-2 DP drive-based, programmable motion controller, designed for industrial motion control applications.

Specification:

Product Type: SIMOTION D435-2 DP Drive-based Control Unit.
Power Supply: Rated DC supply voltage of 24 V.Interfaces:
- Digital Inputs (DI): 12.
- Digital Inputs/Outputs (DI/DO): 16 configurable.
- DRIVE-CLiQ: 6 interfaces for seamless communication with SINAMICS drives.
- PROFIBUS: 2 ports (configurable as master or slave, supporting isochronous mo
Integrated Drive Control: Capable of controlling up to 32 axes, with support for up to 6 servo/vector axes or 12 V/f axes using SINAMICS S120 CU320-2 firmware.
Programming: Programmable using multiple IEC 61131-compliant languages.
Protection Class: IP20.
Dimensions & Weight: Net weight is approximately 3.7 kg.
