Siemens Frequency Converters 6SL3210-1KE11-8UF2

The Siemens 6SL3210-1KE11-8UF2 frequency converter is part of the SINAMICS G120C product series, designed for basic drive applications with integrated energy-saving functions and PROFINET-PN communication.

Specification:

• Rated Power: 0.55 kW (0.75 HP)
• Input Voltage: 3AC 380-480 V (+10% / -20%), 47-63 Hz
• Overload Capacity: 150% overload for 3 seconds
• I/O Interface: 6 digital inputs (DI), 2 digital outputs (DO), 1 analog input (AI), 1 analog output (AO)
• Safety Features: Integrated Safe Torque Off (STO)
• Network (Fieldbus): Integrated PROFINET-PN
• Protection Rating: IP20 / UL Open Type
• Dimensions (H x W x D): FSAA Frame Size (173 mm x 73 mm x 160 mm)
