Siemens Modules 6ES7135-4MB02-0AB0

The Siemens 6ES7135-4MB02-0AB0 electronic module is a 2-channel High Feature (HF) analog output module for the SIMATIC DP ET 200S distributed I/O system, designed for precise process control.

Specification:

• Module Type: High Feature (HF) Analog Output (AO) module.
• Number of Channels: 2 analog output channels for current signals.
• Supply Voltage: 24 V DC (range 20.4-28.8V DC).
• Conversion Time Max: 0.5 ms per channel.
• Max. Load Impedance: 500 Ω with current output.
• Dimensions (HxWxD): 81 mm x 15 mm x 52 mm.
• Weight: Approx. 40 g.
