Siemens Modules 6ES7232-4HA30-0XB0

The Siemens 6ES7232-4HA30-0XB0 is an active-product, analog output signal board (SB 1232) for the SIMATIC S7-1200 series of programmable logic controllers (PLCs). It provides one analog output channel with options for voltage or current signals.

Specification:

• Product type: designation SB 1232, AQ 1×12 bit.
• Number of analog outputs: 1.
• Output ranges: +/-10 V DC (12 bit resolution) or 0-20mA (11 bit resolution).
• Dimensions (W x H x D): 38 mm x 62 mm x 21 mm.
• Weight: Approx. 40 g.
• Power loss, typical: 1.5 W.
• Operating temperature: -20 to 60 °C (horizontal installation).
