Siemens Modules 6ES7288-1SR30-0AA1

The Siemens 6ES7288-1SR30-0AA1 is a Standard CPU (CPU SR30) within the SIMATIC S7-200 SMART PLC series, designed for industrial automation applications. This CPU features an AC/DC/relay configuration and provides integrated digital I/O as well as sufficient program/data memory for various control tasks.

Specification:

• Product Type: Standard CPU SR30 for the SIMATIC S7-200 SMART line.
• Power Supply: Wide AC input range of 85–264 V AC at 47-63 Hz.
• Integrated I/O:
  • Digital Inputs (DI): 18 integrated 24 V DC inputs.
  • Digital Outputs (DQ): 12 integrated relay outputs, rated at 2 A each.
• Memory: A total of 30 KB of program and data memory is available.
• Communication Interfaces:
  • Supports an integrated PROFINET (industrial Ethernet) interface with 10/100 Mbit/s speed.
  • Includes an RS 485 interface for S7 communication and PROFIBUS DP master functionality (up to 187.5 kbps).
• Additional Functions: The PLC supports up to 3 high-speed pulse outputs (up to 100 kHz) for multi-axis control and includes a Micro SD card slot for program/firmware updates.
• Mounting: Designed for standard DIN rail mounting.
