Siemens Plugs 6GK1901-1BB20-2AA0

The Siemens 6GK1901-1BB20-2AA0 is an Industrial Ethernet FastConnect RJ45 plug-in connector designed for reliable connections in industrial automation environments. It features a rugged metal enclosure and the FastConnect termination system for quick and easy onsite assembly.

Specification:

• Connector Type: RJ45 Plug.
• Transmission Rate: 10 Mbit/s, 100 Mbit/s (Fast Ethernet).
• Dimensions (LxWxH): 42 mm x 13.7 mm x 16 mm.
• Net Weight: 35 g.
• PoE Support: Supports Power over Ethernet (PoE and PoE+) capability.
• Reusability: Up to 10 reuses.

Features:

• FastConnect System: Enables quick, error-free assembly without special tools (other than the stripping tool) in the field.
• Rugged Design: The metal housing provides resistance to wear, abrasion, and industrial conditions, ensuring longevity.
• Integrated Strain Relief: Provides maximum strength and minimal risk of damage when the cable is bent.
• Application: Suitable for point-to-point links (up to 100 m) in industrial automation and business data centers.
