Siemens Reader 6GT2002-0HD00

The Siemens Reader 6GT2002-0HD00 is an RF170C RFID communication module designed to act as an interface for integrating Siemens RFID read/write devices into an industrial automation system, specifically as part of a distributed I/O system (ET 200pro) via PROFIBUS.

Specification:

• Function: Acts as a communication interface module between RFID readers (e.g., RF200, RF300 series) and a central controller (PLC) using the PROFIBUS fieldbus protocol via a compatible ET 200pro head module.
• Reader Connectivity: It can connect up to two RFID read/write devices.
• Interface Type: Features an RS422 interface for point-to-point connections via a connection block.
• Communication: Supports S7 communication and can be operated in “RFID standard profile” mode, utilizing function blocks (FB 101/116/132) or the Ident Library in SIMATIC S7 controllers.
• Data Transfer Rate: The maximum serial transfer rate at the point-to-point connection is 115.2 kbit/s.
• Reliability: It boasts a high Mean Time Between Failures (MTBF) rating of 129 years.
